RHINO – FUNDAMENTALS

Day 1

Drawing in 2D

·    Overview of Lines and Polylines

·    Constructing Rectangles and Polygons

·    Drawing Arcs, Circles, and Ellipses

·    Creating Free-Form Curves

Modeling Simple Surfaces

·    Construction Stratagems

·    3D Surface Types

·    New Curve Extrusion Types

·    Modeling with Extrusions

·    Lofting to Create Surfaces

·    Create Surfaces with Revolve and Rail

·    Sweep 1 and 2 Rail Options

·    Network Surface for Complex Surfaces

Creating 3D Solids

·    Creating a Simple 3D Set and Props

·    Solids Overview

·    Creating Solids with Primitives

·    Creating Solids with Extruded Curves

·    Boolean Functions

·    Workarounds for Solids and Booleans

·    Utilizing New Solid Control Points

·    Sub-Object Selection

Day 2

Aids in Modeling

·    Deconstructing Modeling Aids

·    Grid Snap and Attributes

·    Orthographic Modeling

·    Planar Modeling Aid

·    Object Snaps

·    Utilizing Cursor Constraints

·    SmartTrack Selection Filter Dialogue

·    Isometric Settings

·    Establish Symbology and Layout Settings

·    Quick Isos

·    Production Isos

·    Edit Iso

·    Export to Pipe Component File (.PCF)

Transform and Edit

·    Modifying a Simple 3D Set and Props

·    Using Fillet and Chamfer on Corners

·    Trim and Split

·    Drag and Nudge

·    Copy and Paste

·    Undo and Redo

·    Group Objects

·    Scale Objects

·    Mirror Command and Alternative Functions

·    Utilize Arrays for Sets and Copies
